Industrial-Scale Cleaning Power with Dual Impeller Agitation
When you need serious cleaning capacity, the AT-35 delivers. With a massive 36" x 60" inside tank and 350-gallon solution capacity, this hot tank handles large engine blocks, heavy components, and high-volume cleaning jobs that smaller tanks simply can't. AXE Equipment's exclusive dual impeller design creates exceptional agitation throughout the entire tank — combined with high temperatures, it cuts through grease, grime, and buildup fast.
Fully insulated for superior heat retention and energy efficiency, the AT-35 features a spring-loaded lid for easy loading and unloading of heavy parts. Available in Gas or Electric heat to match your shop's infrastructure.
- Exclusive dual impeller agitation for thorough, even cleaning across a large tank
- 350-gallon solution capacity — handles the biggest jobs
- 36" x 60" inside tank dimensions
- Gas (125,000 BTU) or Electric (21,500W, 230V 3-phase) heat options
- 2 HP agitation motor (230–460V)
- Full 1" insulation with 16-gauge covering for energy efficiency
- Spring-loaded lid for easy loading and unloading of large parts
- 7-day timer included standard
- Optional basket with lift bar and H-20 hoist availble
Ready to outfit your shop with the AT-35? Contact us — we're happy to answer questions and help you configure the right setup.
Specifications
| SPECIFICATION | AT-35 |
|---|---|
| Floor Space | 48"W X 78"L X 50"H |
| Inside Tank | 36"W X 60"L X 30"H |
| Loading Height | 42" |
| Solvent Depth | 24" |
| Solution Capacity | 350 gallons |
| Tank Construction | 12 gauge |
| Grate Construction | 9/16" rod x 1/4" X 3/4" flat |
| Insulation | 1" |
| Insulation Covering | 16 gauge |
| Electric Heater | 21,500 Watts |
| Heater Voltage | 230 V 3 Phase |
| Heater Amp Draw | 45 amps |
| Gas Burner | 125,000 btu |
| Motor Size/Voltage | 2 hp = 230-460 |
| Motor Amp Draw | 6.0 - 3.0 amps |
| Agitation Pumps | Two |
| Shipping Weight | 1,625 LBS |
| Basket w/Lift Bar | Optional |
| OPTIONS | |
| Electric Heater – 460V | n/a |
| Motor 1 Phase | 2 hp = 9.0 amps |
| Hoist (Telescopic Boom) | H-20 |
| Basket w/Lift Bar | 34"W X 58"L X 12"D |
| Parts Basket | 8"W X 12"L X 12"D |
