The AT-35 has a large 36" 60" inside tank capacity along with a spring loaded lid for easy loading and unloading. Our exclusive dual impeller design creates remarkable agitation for remarkable cleaning results. Combine the agitation with high temperatures and you have a great cleaner at an affordable price. Like all AXE Equipment Hot Tanks The AT-35 is completely insulated for great heat retention and energy efficiency. Available in Gas or Electric heat.
| SPECIFICATIONS: | AT-35 |
| Floor Space | 48"W X 78": X 50"H |
| Inside Tank | 36"W X 60"L X 30"H |
| Loading Height | 42" |
| Solvent Depth | 24" |
| Solution Capacity | 350 gallons |
| Tank Construction | 12 gauge |
| Grate Construction | 9/16" rod x 1/4" X 3/4" flat |
| Insulation | 1" |
| Insulation Covering | 16 gauge |
| Electric Heater | N/A |
| Heater Voltage | N/A |
| Heater Amp Draw | N/A |
| Gas Burner | 125,000 btu |
| Motor Size/Voltage | 2 hp=230-460 |
| Motor Amp Draw | 6.0 - 3.0 amps |
| Agitation Pumps | two |
| Shipping Weight | 1625 LBS |
| Basket w/Lift Bar | Optional |
| OPTIONS | |
| Electric Heater- 1 Phase | n/a |
| Electric Heater- 460 v | n/a |
| Motor 1 phase | 2 hp= 9.0 amps |
| 7-Day Timer | 50-0701 |
| Hoist (Telescopic Boom) | H-20 |
| Basket w/Lift Bar | 34"W X 58"L X 12"D |
| Parts Basket | 8"W X 12"L X 12"D |
