The Most Powerful Spraywasher in the AXE Lineup — Built for Serious Rebuilders
The AXE Blue Max SW-2832 is the top-of-the-line combination spraywasher and hot tank, engineered for shops that demand maximum cleaning performance. The spacious 28" diameter turntable accommodates studded block applications, while the 32" vertical height handles most any 6-cylinder block application with room to spare.
Where the Blue Max truly sets itself apart is the cleaning system. A large 2" diameter manifold with smooth-radius elbows in a full 360° design eliminates flow restrictions, and the 7.5 HP pump delivers 100 gallons of hot water per minute at 70 psi — quickly shearing away grease and grime from every surface. The spring-loaded lay-down door and roll-out turntable make loading and unloading easy, and the lay-down door design keeps your shop floor drier and cleaner.
- 28" diameter heavy-duty turntable — accommodates studded block applications
- 32" vertical chamber height for most 6-cylinder block applications
- 7.5 HP pump delivering 100 gpm at 70 psi through 20 alternating spray nozzles
- 2" diameter 360° manifold with smooth-radius elbows for unrestricted flow
- 700 lb load weight capacity
- Spring-loaded lay-down door keeps the shop floor drier and cleaner
- Built-in hot tank standard on all models
- 1" fiberglass insulation for energy efficiency
- Gas or electric heat available on all configurations
- Standard tooling includes clamping fixture for cylinder heads, intakes, cranks, and other components
Choose Your Configuration
The Blue Max SW-2832 is available in three configurations, each available in gas or electric heat:
- SW-2832-R (Standard): 110-gallon solution capacity, 24" x 34" x 11" built-in hot tank — the core Blue Max setup for high-volume rebuilding shops.
- SW-2832-HT (Extended Front Hot Tank): 140-gallon solution capacity, 13" x 34" x 11" built-in hot tank — adds extended hot tank capacity for shops doing heavy soaking work.
- SW-2832-EX (Extra Wide Extended Front Hot Tank): 160-gallon solution capacity, 24" x 55" x 11" built-in hot tank — maximum hot tank size for the highest-volume or most demanding applications.
Not sure which configuration is right for your shop? Contact us — we're happy to help.
Optional Accessories
Specifications
| SPECIFICATION | SW-2832-HT | SW-2832-R | SW-2832-EX |
|---|---|---|---|
| WORK CAPACITY | |||
| Height | 32" | 32" | 32" |
| Turntable Dia. | 28" | 28" | 28" |
| Load Weight Capacity | 700 lbs | 700 lbs | 700 lbs |
| FLOOR SPACE REQUIRED | |||
| Height | 66" | 66" | 66" |
| Width | 54" | 54" | 73" |
| Length: Door Open | 80" | 80" | 80" |
| Length: Door Closed | 65" | 60" | 65" |
| Turntable Height (Above Floor) | 27" | 27" | 27" |
| SHIPPING WEIGHT | |||
| Shipping Weight | 1,600 lbs | 1,400 lbs | 1,800 lbs |
| CLEANING SYSTEM | |||
| Solution Capacity | 140 gals. | 110 gals. | 160 gals. |
| Pump Motor | 7.5 HP | 7.5 HP | 7.5 HP |
| Pump Output | 70 psi @ 100 gpm | 70 psi @ 100 gpm | 70 psi @ 100 gpm |
| Spray Nozzles | 20 alternating | 20 alternating | 20 alternating |
| Filter Screen | 1,450 sq. in. | 1,200 sq. in. | 2,530 sq. in. |
| CABINET CONSTRUCTION | |||
| Gauge Steel | 12 ga. inner / 16 ga. outer | 12 ga. inner / 16 ga. outer | 12 ga. inner / 16 ga. outer |
| Insulation | 1" fiberglass | 1" fiberglass | 1" fiberglass |
| Steam Vent | 6" | 6" | 6" |
| Gas Vent | 6" | 6" | 6" |
| HEAT SOURCE | |||
| Electric Element | 12 KW | 12 KW | 15 KW |
| Gas Burner | 100,000 BTU | 100,000 BTU | 150,000 BTU |
| HOT TANK BASKETS | |||
| Width (I.D.) | 13" | 24" | 24" |
| Length (I.D.) | 34" | 34" | 55" |
| Depth (I.D.) | 11" | 11" | 11" |
| ELECTRICAL REQUIREMENTS (3 PHASE) | |||
| Pump Motor 3 Phase | 208/230/460V: 21/18/9.4 Amps | — | |
| Electric Heat 3 Phase | (12 KW) 208/230/460V: 33-29-17 Amps | (12 KW) 208/230/460V: 33-29-17 Amps | (15 KW) 208/230/460V: 41-37-19 Amps |
| ELECTRICAL OPTIONS (1 PHASE) | |||
| Pump Motor 1 Phase | 230 Volts, 33 Amps | — | |
| Electric Heater 1 Phase | (12 KW) 230 Volts, 52 Amps | (12 KW) 230 Volts, 52 Amps | (15 KW) 230 Volts, 65 Amps |
| STANDARD EQUIPMENT | |||
| Low Water Switch | Standard | ||
| Dual 7 Day Timers | Standard | ||
| Digital Temp Controller | Standard | ||
| Head Rack / Crank Rack | Standard | ||
| Auto Air Inducer | Standard | ||
| Short Circuit & Thermal Protection | Standard | ||
| Lay Down Door / Seal-less | Standard | ||
| V-Bottom Floor | Standard | ||
| Built-in Hot Tank | Standard | ||
| 360 Degree Manifold | Standard | ||
| 1" Fiberglass Insulation | Standard | ||
| Warranty | One Year | ||
